Description
PERFORMANCE
Processor
Intel® Core i3-1315U, 6C (2P + 4E) / 8T, P-core 1.2 / 4.5GHz, E-core 0.9 / 3.3GHz, 10MB
Graphics
Integrated Intel® UHD Graphics
Chipset
Intel® SoC Platform
Memory
8GB Soldered DDR4-3200
Memory Slots
One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
Max Memory
Up to 40GB (8GB soldered + 32GB SO-DIMM) DDR4-3200
Storage
256GB SSD M.2 2242 PCIe® 4.0×4 NVMe® Opal 2.0
Storage Slot
Two M.2 slots
One M.2 2242 PCIe® 3.0 x4 slot
One M.2 2242 PCIe 4.0 x4 slot
Max Storage Support
Up to two drives, 2x M.2 SSD
M.2 2242 SSD up to 1TB each
Optical
None
Card Reader
No card reader
Audio Chip
High Definition (HD) Audio, Synaptic® CX11880 codec
Speakers
Stereo speakers, 2W x2, Dolby Atmos®
Microphone
2x, Array
Camera
HD 720p with Privacy Shutter
Battery
57Wh
Power Adapter
65W USB-C® (3-pin)
DESIGN
Display
16 WUXGA (1920×1200) IPS 300nits Anti-glare, 45% NTSC
Touchscreen
None
Screen-to-Body Ratio
90.7%
Pen
Pen Not Supported
Keyboard
Backlit, English (UK)
Dimensions (WxDxH)
356.1 x 247.7 x 19.85 mm (14.02 x 9.75 x 0.78 inches)
Weight
Starting at 1.77 kg (3.90 lbs)
Case Color
Graphite Black
Case Material
Aluminium (Top), PC-ABS (Bottom)
SOFTWARE
Operating System
Windows® 11 Pro, English
Bundled Software
None
CONNECTIVITY
WLAN + Bluetooth
Intel® Wi-Fi® 6 AX201, 802.11ax 2×2 + BT5.1
WWAN
Non-WWAN
SIM Card
None
Ethernet
100/1000M (RJ-45)
NFC
None
Standard Ports
1x USB 2.0
1x USB 3.2 Gen 1 (Always On)
1x USB-C® 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
1x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
Docking
Various docking solutions supported via Thunderbolt™ or USB-C®.
For more compatible docking solutions, please visit Docking for ThinkPad® E16 Gen 1 (Intel®)
SECURITY & PRIVACY
Security Chip
Discrete TPM 2.0 Enabled
Physical Locks
Kensington® Nano Security Slot, 2.5 x 6 mm
Smart Card Reader
None
Fingerprint Reader
None
Other Security
Camera privacy shutter
ThinkShield
MANAGEABILITY
System Management
Non-vPro®
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
None
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ENERGY STAR® 8.0
EPEAT™ Gold Registered
ErP Lot 6/26
FSC certified package
RoHS compliant
TCO Certified 9.0
Mil-Spec Test
MIL-STD-810H military test passed
Other Certifications
TUV Rheinland® Low Blue Light (Software Solution)
